MS27467E23B2SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 85 POS Crimp ST Cable Mount 85 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $309.12
Unit Price: USD $309.1176
≥1 USD $309.1176
≥10 USD $299.6048
≥100 USD $295.064
≥500 USD $290.664
≥1000 USD $286.3872
≥3000 USD $270.4768
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 30.96mm
Technical
Plating Cadmium
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 23-2
Shell Finish Olive Drab Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 5A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation A
Total Number of Contacts 85
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Military
Color Olive Drab
Number of Positions 85
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
