MS27467E23A55S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL INDUSTRIAL MS27467E23A55S CONNECTOR, CIRC, 23-54, 53WAY, SIZE 23
PDF
/
Inventory: 7747
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Ingress Protection Environment Resistant
Current Rating 7.5A
Shell Finish Cadmium over Nickel
Shell Size - Insert 23-55
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 55
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Military
Number of Positions 55
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
