MS27466E13B4P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CIRCULAR, SIZE 13, 4WAYS, PIN
PDF
/
Buying Options
Total Price: USD $86.39
Unit Price: USD $86.394229
≥1 USD $86.394229
≥10 USD $81.503984
≥100 USD $76.890558
≥500 USD $72.538258
≥1000 USD $68.432321
Inventory: 4615
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
JESD-609 Code e4
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 4
Color Olive Drab
Applications Aviation, Marine, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 28.57mm
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 13-4
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Cadmium
Dimensions
Length 30.81mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
