MS17344C22C23S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-C-22992 Circular SKT 8 POS Crimp ST Cable Mount 8 Terminal 1 Port
PDF
/
Inventory: 7787
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Technical
Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Number of Contacts 8
Shell Size - Insert 22-23
Shell Finish Conductive Cadmium
Ingress Protection Waterproof
Shielding Unshielded
Orientation N (Normal)
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Gender Male
Applications Industrial, Military
Number of Positions 8 (Power)
Connector Type Plug, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut
Series Military, MIL-DTL-22992
Published 2003
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
