Package /
Category Connectors, Interconnects / Circular Connectors
Description STANDARD: MIL-C-83723COMPATIBLE CONTACT: M39029/4-110 Circular Connector
PDF
/
Inventory: 3060
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 5
Shell Size - Insert 10-5
Shell Finish Electroless Nickel
Current Rating 7.5A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-83723, COMPATIBLE CONTACT: M39029/4-110
Gender Male
Applications Automotive, Military
Color Silver
Number of Positions 5 (Power)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-83723 Series III
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Shell Material Aluminum
Number of Pins 20
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
