M83723/76A16109
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 1460
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 16-10
Shell Finish Black Anodized
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation 9
Total Number of Contacts 10
Current Rating (Amps) 13A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Applications Automotive, Military
Color Black
Number of Positions 10 (Power)
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series Military, MIL-DTL-83723 Series III
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Number of Pins 10
Mounting Type Free Hanging (In-Line)
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
