M83723/72W1808N
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Buying Options
Total Price: USD $44.49
Unit Price: USD $44.4928
≥1 USD $44.4928
≥10 USD $43.164
≥100 USD $41.9144
≥500 USD $40.1632
≥1000 USD $39.6176
≥3000 USD $38.5616
Inventory: 73
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Plating Cadmium
Backshell Type SOLID
Empty Shell NO
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 8
Shell Size - Insert 18-8
Shell Finish Olive Drab Cadmium
Military Standard MIL-DTL-83723
Current Rating 23A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Automotive, Military
Color Olive Drab
Number of Positions 8 (Power)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-83723 Series III
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum
Number of Pins 12
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
