M83723/71W24616
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-83723COMPATIBLE CONTACT: M39029/5-115 Circular Connector
PDF
/
Buying Options
Total Price: USD $66.29
Unit Price: USD $66.2904
≥1 USD $66.2904
≥10 USD $64.3104
≥100 USD $62.4536
≥500 USD $59.8488
≥1000 USD $59.0304
≥3000 USD $57.4552
Inventory: 24
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-83723 Series III
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 61 (Power)
Color Olive Drab
Applications Automotive, Military
Gender Female
Additional Feature STANDARD: MIL-C-83723, COMPATIBLE CONTACT: M39029/5-115
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 7.5A
Orientation 6
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 24-61
Number of Contacts 61
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
