JTPQ00RE-18-68S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 18 POS Crimp ST Wall Mount 18 Terminal 1 Port
PDF
/
Inventory: 1703
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 24.05mm
Technical
Plating Cadmium
Number of Contacts 18
Shell Size - Insert 18-68
Shell Finish Cadmium over Nickel
Depth 33.32mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Female
Applications Aviation, Marine, Military
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 18
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series II, JT
Published 2013
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Wall
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
