JTP02RE-20-16SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL JTP02RE-20-16SA Circular Connector, MIL-C-38999 Series II, Receptacle, 16 Contacts, Socket, Crimp, Panel Mount
PDF
/
Inventory: 4603
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Box
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series II, JT
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 16
Applications Aviation, Marine, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 16
Orientation A
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 36.52mm
Shell Finish Cadmium over Nickel
Shell Size - Insert 20-16
Empty Shell NO
Backshell Type SOLID
Plating Cadmium
Dimensions
Length 17.06mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
