JTP02RE-10-98S-014
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 6P JT Series MIL-DTL-27599
PDF
/
Inventory: 5300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 10-98
Shell Finish Olive Drab Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 6
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code no
Series MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
