JTG06RP14-15S image
Favorite
JTG06RP14-15S image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description AMPHENOL JTG06RP14-15S Circular Connector, MIL-C-38999 Series II, Plug, 15 Contacts, Socket, Crimp, Cable Mount
PDF
/
Inventory: 4092
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 14-15
Shell Finish Cadmium over Nickel
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 15
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-DTL-38999
Gender Male
Applications Aviation, Marine, Military
Number of Positions 15
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Potted
Series MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy
