JT07RT14-35S-023
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-38999COMPATIBLE CONTACT: 10-597261-722 Circular Connector
PDF
/
Buying Options
Total Price: USD $97.76
Unit Price: USD $97.755144
≥1 USD $97.755144
≥10 USD $92.221831
≥100 USD $87.001731
≥500 USD $82.077104
≥1000 USD $77.431226
Inventory: 8174
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 14-35
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 37
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: 10-597261-722
Gender Female
Applications Aviation, Marine, Military
Color Silver
Number of Positions 37
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series II, JT
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Aluminum Alloy
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Jam Nut
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
