JT06RT-22-14S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 14 POS Crimp ST Cable Mount 14 Terminal 1 Port
PDF
/
Inventory: 7402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Series MIL-DTL-38999 Series II, JT
Feature Coupling Nut
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 14
Applications Aviation, Marine, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 14
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Cadmium over Nickel
Shell Size - Insert 22-14
Empty Shell NO
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
