JT06RT-20-35S-014
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Cadmium over Nickel MIL-DTL-38999Series II JT Non-RoHS Compliant 2006 Circular Connector -65C~175C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $137.26
Unit Price: USD $137.262721
≥1 USD $137.262721
≥10 USD $129.493133
≥100 USD $122.16333
≥500 USD $115.248422
≥1000 USD $108.724934
Inventory: 5536
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 20-35
Shell Finish Olive Drab Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 79
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: 10-597261-722
Applications Aviation, Marine, Military
Color Olive Drab
Number of Positions 79
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut
Series MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
