JT06RT-16-8S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical SKT 8 POS Crimp ST Cable Mount 8 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $97.17
Unit Price: USD $97.170716
≥1 USD $97.170716
≥10 USD $91.670491
≥100 USD $86.48159
≥500 USD $81.586411
≥1000 USD $76.968311
Inventory: 2996
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 22.63mm
Technical
Plating Cadmium
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 16-8
Shell Finish Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 8
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Gender Male
Applications Aviation, Marine, Military
Number of Positions 8
Connector Type Plug, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Coupling Nut
Series MIL-DTL-38999 Series II, JT
Published 2014
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 9 Weeks
