JT06RE24-35P-023 image
Favorite
JT06RE24-35P-023 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description CIRCULAR, SIZE 24, 128WAYS, PIN
PDF
/
Inventory: 8178
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 23.82mm

Technical

Plating Electroless Nickel
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 24-35
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 128
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: LP-251415-725
Gender Male
Applications Aviation, Marine, Military
Color Silver
Number of Positions 128
Connector Type Plug, Male Pins
Termination Crimp
Part Status Active
Pbfree Code no
Feature Coupling Nut
Series MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 12 Weeks
