JT06RE22-55P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL JT06RE22-55P Circular Connector, MIL-C-38999 Series II, Plug, 55 Contacts, Pin, Crimp, Cable Mount
PDF
/
Inventory: 6611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 23.82mm
Technical
Plating Cadmium
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 22-55
Shell Finish Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 55
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-C-38999, EMI SHIELDED
Gender Male
Applications Aviation, Marine, Military
Number of Positions 55
Connector Type Plug, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series MIL-DTL-38999 Series II, JT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material Copper Alloy
