Package /
Category Connectors, Interconnects / Circular Connectors
Description STANDARD: MIL-DTL-38999COMPATIBLE CONTACT: 10-251415-165 Circular Connector
PDF
/
Inventory: 2040
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper Alloy
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy

Technical

Operating Temperature -65°C~175°C
Packaging Bulk
Published 2013
Series MIL-DTL-38999 Series II, JT
Feature Coupling Nut
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 13
Applications Aviation, Marine, Military
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: 10-251415-165
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 13
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Shell Finish Cadmium over Nickel
Shell Size - Insert 16-13
Empty Shell NO
Backshell Type SOLID

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

RoHS Status Non-RoHS Compliant
