JT02RE-10-13P image
Favorite
JT02RE-10-13P image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description AMPHENOL JT02RE-10-13P Circular Connector, MIL-C-38999 Series II, Receptacle, 13 Contacts, Pin, Crimp, Panel Mount
PDF
/
Inventory: 2071
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 22.76mm

Technical

Plating Cadmium
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 10-13
Shell Finish Cadmium over Nickel
Depth 23.82mm
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 13
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACT: M39029/58-361
Gender Receptacle
Applications Aviation, Marine, Military
Number of Positions 13
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Pbfree Code no
Series MIL-DTL-38999 Series II, JT
Published 2000
Packaging Bulk
Operating Temperature -65°C~175°C

Physical

Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Box
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
