D38999/26TF18PC image
Favorite
D38999/26TF18PC image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN PLUG MALE 18POS GOLD CRIMP
PDF
/
Inventory: 1821
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 18
Shell Material Aluminum

Technical

Operating Temperature -65°C~175°C
Packaging Bulk
Published 2012
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 18 (14 + 4 Twinax)
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation C
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Durmalon?
Shell Size - Insert 19-18
Shell Size, MIL F

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

RoHS Status ROHS3 Compliant
Ratings Environment Resistant
