D38999/26JJ29SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG FMALE 29POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $80.79
Unit Price: USD $80.7928
≥1 USD $80.7928
≥10 USD $77.6864
≥100 USD $74.8088
≥500 USD $69.6432
≥1000 USD $65.1552
≥3000 USD $60.2888
Inventory: 103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Composite
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2011
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Feature Coupling Nut, Self Locking
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 29
Color Olive Drab
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 29
Orientation A
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Olive Drab Cadmium
Shell Size - Insert 25-29
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Shell Size, MIL J
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
