D38999/26JB2SD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Cadmium Military MIL-DTL-38999Series III Tri-Start? TV Non-RoHS Compliant Environment Resistant Circular Connector -65C~175C 50.0muin 1.27mum
PDF
/
Inventory: 7729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Composite
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Feature Coupling Nut, Self Locking
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 2
Color Olive Drab
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 2
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Olive Drab Cadmium
Shell Size - Insert 11-2
Empty Shell NO
Contact Style Socket
Environmental Characteristics CORROSION RESISTANT
Body Plating Cadmium
Shell Size, MIL B
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
