D38999/24MD15PN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 15POS GOLD CRIMP
PDF
/
Inventory: 1315
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 31.9mm
Technical
Contact Quantities 14,1
Shell Size, MIL D
Plating Electroless Nickel, Nickel
Contact Size 2016
Contact Style Pin
Empty Shell NO
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 15-15
Shell Finish Electroless Nickel
Military Standard MIL-DTL-38999
Current Rating 13A
Depth 38.1mm
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 15
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Applications Aerospace, Aviation, Military
Color Silver
Number of Positions 15
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Aluminium, Composite
Shell Material Composite
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
