D38999/24MC98SN image
Favorite
D38999/24MC98SN image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular MIL Spec Connector 10P SIZE 13 JAM NUT RECEPTACLE SKT
PDF
/
Buying Options
Total Price: USD $223.91
Unit Price: USD $223.9072
≥1 USD $223.9072
≥10 USD $207.4908
≥100 USD $200.027168
Inventory: 80
Minimum: 1
-
+

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Contact Quantities 10
Shell Size, MIL C
Plating Electroless Nickel
Contact Size 20
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 13-98
Shell Finish Electroless Nickel
Military Standard MIL-DTL-38999
Current Rating 7.5A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 10
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Receptacle
Applications Aerospace, Aviation, Military
Color Silver
Number of Positions 10
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C

Physical

Shell Material Composite
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
