D38999/20ZF28SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Black Zinc Nickel Military MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~175C 50.0muin 1.27mum
PDF
/
Inventory: 2762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Shell Size, MIL F
Shell Size - Insert 19-28
Shell Finish Black Zinc Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Receptacle
Applications Aviation, Marine, Military
Color Black
Number of Positions 28
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
Published 2013
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Body Material Aluminium
Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
