D38999/20KF35SB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Passivated Military MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 36.9mm
PDF
/
Inventory: 7559
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 32.74mm
Technical
Shell Size, MIL F
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 19-35
Shell Finish Passivated
Depth 36.9mm
Ingress Protection Environment Resistant
Shielding Shielded
Orientation B
Total Number of Contacts 66
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Female
Applications Aviation, Marine, Military
Number of Positions 66
Connector Type Receptacle, Female Sockets
Termination Crimp
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
Published 2001
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Shell Material Stainless Steel
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
