D38999/20JD35PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Olive Drab Cadmium Military MIL-DTL-38999Series III Tri-Start? TV Non-RoHS Compliant 2004 Circular Connector -65C~175C 31.3mm
PDF
/
Buying Options
Total Price: USD $39.64
Unit Price: USD $39.644
≥1 USD $39.644
≥10 USD $38.1216
≥100 USD $36.7136
≥500 USD $34.1792
≥1000 USD $31.9704
≥3000 USD $29.5856
Inventory: 54
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Length 32.69mm
Technical
Shell Size, MIL D
Plating Cadmium
Contact Style Pin
Empty Shell NO
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 15-35
Shell Finish Olive Drab Cadmium
Military Standard MIL-DTL-38999
Depth 31.3mm
Ingress Protection Environment Resistant
Shielding Shielded
Orientation C
Total Number of Contacts 37
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Applications Aerospace, Aviation, Military
Color Olive Drab
Number of Positions 37
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
Published 2004
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Composite
Mounting Feature Flange
Mounting Type Panel Mount
Mount Wall
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
