D38999/20FE2SN image
Favorite
D38999/20FE2SN image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description AMPHENOL D38999/20FE2SN Circular Connector, MIL-DTL-38999 Series III, Wall Mount Receptacle, 39, Crimp Socket, Threaded
PDF
/
Inventory: 5920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Body Material Aluminium

Technical

Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 39 (38 + 1 Twinax)
Color Silver
Applications Aviation, Marine, Military
Gender Receptacle
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Depth 36.9mm
Current Rating 5A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 17-2
Number of Contacts 39
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Electroless Nickel
Body Plating Electroless Nickel
Shell Size, MIL E

Dimensions

Length 32.74mm
Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
