RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description STANDARD: MIL-C-38999COMPATIBLE CONTACT: 10-251415-205 Circular Connector
PDF
/
Buying Options
Total Price: USD $229.94
Unit Price: USD $229.939707
≥1 USD $229.939707
≥10 USD $216.924251
≥100 USD $204.645518
≥500 USD $193.061812
≥1000 USD $182.13378
Inventory: 9372
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 2 Weeks

Physical

Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Composite
Insert Material Thermoplastic

Technical

Operating Temperature -65°C~200°C
Packaging Bulk
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 61
Color Silver
Applications Aviation, Marine, Military
Gender Female
Additional Feature STANDARD: MIL-C-38999, COMPATIBLE CONTACT: 10-251415-205
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 61
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 25-61
Empty Shell NO
Backshell Type SOLID

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
