CTVS07RF-25-37SA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $312.96
Unit Price: USD $312.959
≥1 USD $312.959
≥10 USD $295.24434
≥100 USD $278.532399
≥500 USD $262.766408
≥1000 USD $247.892841
Inventory: 1657
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 37
Color Silver
Applications Aviation, Marine, Military
Gender Receptacle
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Total Number of Contacts 37
Orientation A
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 25-37
Empty Shell YES
Backshell Type SOLID
Body Plating Electroless Nickel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
