CTVS07RF-23-35S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular SKT 100 POS Crimp ST Jam Nut 100 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $1727.85
Unit Price: USD $1727.8536
≥1 USD $1727.8536
≥10 USD $1511.8752
≥100 USD $1343.9008
≥500 USD $965.2016
Inventory: 122
Minimum: 1
-
+
Technical Details
Physical
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Composite
Insert Material Thermoplastic
Contact Material Copper Alloy
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 100
Color Silver
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Depth 52.37mm
Shell Finish Electroless Nickel
Shell Size - Insert 23-35
Plating Electroless Nickel
Dimensions
Length 31.9mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
Supply Chain
Factory Lead Time 16 Weeks
