CTVS07RF-19-11PB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 11POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $616.8
Unit Price: USD $616.8008
≥1 USD $616.8008
≥10 USD $539.704
≥100 USD $479.6352
≥500 USD $350.02
Inventory: 111
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 19-11
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation B
Total Number of Contacts 11
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Additional Feature TRI-START, STANDARD: MIL-DTL-38999
Gender Female
Applications Aviation, Marine, Military
Color Silver
Number of Positions 11
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2001
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Composite
Number of Pins 16
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Panel
Contact Material Copper Alloy
