CTVS07RF-13-98SC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Electroless Nickel MIL-DTL-38999Series III Tri-Start? TV ROHS3Compliant Environment Resistant Circular Connector -65C~200C 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $614.53
Unit Price: USD $614.5304
≥1 USD $614.5304
≥10 USD $537.7152
≥100 USD $477.9368
≥500 USD $348.8144
Inventory: 61
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 13-98
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation C
Total Number of Contacts 10
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Additional Feature TRI-START, STANDARD: MIL-DTL-38999
Gender Female
Applications Aviation, Marine, Military
Color Silver
Number of Positions 10
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2013
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Composite
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
