CTVS06RF-17-26SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG FMALE 26POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $109.99
Unit Price: USD $109.9912
≥1 USD $109.9912
≥10 USD $95.3304
≥100 USD $84.1104
≥500 USD $75.2576
≥1000 USD $65.9912
Inventory: 166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2001
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Female Sockets
Number of Positions 26
Color Silver
Applications Aviation, Marine, Military
Gender Male
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 26
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 17-26
Empty Shell YES
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
