CTVS06RF-17-26PB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular PIN 26 POS Crimp ST Cable Mount 26 Terminal 1 Port
PDF
/
Inventory: 2491
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 26
Color Silver
Applications Aviation, Marine, Military
Gender Male
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 26
Orientation B
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 17-26
Empty Shell YES
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
