CTVS06RF-15-5SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG FMALE 5POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $628.74
Unit Price: USD $628.7424
≥1 USD $628.7424
≥10 USD $550.1496
≥100 USD $488.9632
≥500 USD $352.44
Inventory: 151
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Empty Shell YES
Shell Size - Insert 15-5
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation D
Total Number of Contacts 5
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Aviation, Marine, Military
Color Silver
Number of Positions 5
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2001
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Composite
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
