CTVS06RF-15-19PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE 19POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $113.12
Unit Price: USD $113.119529
≥1 USD $113.119529
≥10 USD $106.716543
≥100 USD $100.675986
≥500 USD $94.977346
≥1000 USD $89.601268
Inventory: 8568
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 20
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2001
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Coupling Nut, Self Locking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 19
Color Silver
Applications Aviation, Marine, Military
Gender Male
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 19
Orientation C
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 15-19
Empty Shell YES
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
