CTVPS00RF-25-29HN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 29POS GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $150.44
Unit Price: USD $150.436
≥1 USD $150.436
≥10 USD $130.3808
≥100 USD $115.0424
≥500 USD $102.9336
≥1000 USD $90.2616
Inventory: 110
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Number of Pins 29
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 29
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color Silver
Applications Aviation, Marine, Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 25-29
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
