CTVPS00RF-25-19JB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 19POS GOLD CRIMP
PDF
/
Inventory: 5091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Composite
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2001
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 19
Color Silver
Applications Aviation, Marine, Military
Gender Female
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 19
Orientation B
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 25-19
Empty Shell YES
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
