CTVPS00RF-11-99PB image
Favorite
CTVPS00RF-11-99PB image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN RCPT MALE 7POS GOLD CRIMP
PDF
/
Inventory: 1968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Composite
Insert Material Thermoplastic

Technical

Operating Temperature -65°C~200°C
Packaging Bulk
Published 2001
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 7
Color Silver
Applications Aviation, Marine, Military
Additional Feature TRI-START, STANDARD: MIL-DTL-38999
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 7
Orientation B
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 11-99
Empty Shell YES
Backshell Type SOLID
Environmental Characteristics CORROSION RESISTANT

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

RoHS Status ROHS3 Compliant
Ratings Environment Resistant
