Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 1499
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Number of Pins 23
Shell Material Composite

Technical

Operating Temperature -65°C~175°C
Packaging Bulk
Published 2012
Series MIL-DTL-38999 Series III, Tri-Start? HD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 9
Color Silver
Applications Military
Fastening Type Threaded
Contact Finish - Mating Gold
Orientation D
Shielding Shielded
Ingress Protection Environment Resistant
Reach Compliance Code unknown
Shell Finish Electroless Nickel
Shell Size - Insert 9-9

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

RoHS Status ROHS3 Compliant
Ratings Environment Resistant
