91-569764-18S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 4021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Wall
Mounting Type Panel Mount, Through Hole
Mounting Feature Flange
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Series MIL-DTL-38999 Series III, Tri-Start? TV
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 18
Color Silver
Applications Aviation, Marine, Military
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 18
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Shell Finish Electroless Nickel
Shell Size - Insert 15-18
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
