2M805-002-16M9-10PB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
M805 10C 10#23 PIN PLUG THRD
PDF
/
Inventory: 2732
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Insulation Resistance 5GOhm
Contact Style Pin
Number of Contacts 10
Shell Size - Insert 9-10
Shell Finish Electroless Nickel
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Shielded
Orientation B
Current Rating (Amps) 5A
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Male
Color Silver
Number of Positions 10
Connector Type Plug, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut, Self Locking
Series 2M
Published 2011
Packaging Bulk
Operating Temperature -65°C~150°C
Physical
Insert Material Polyphenylene Sulfide (PPS)
Shell Material Aluminum Alloy
Number of Pins 23
Mounting Type Free Hanging (In-Line)
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
