2M801-009-07NF9-200SA

Amphenol Aerospace Operations
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description M801 6C 4#23 2#16 SKT RECP OM
PDF
/
Inventory: 3153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum Alloy
Insert Material Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -65°C~150°C
Packaging Bulk
Published 2011
Series 2M
Feature Backshell
Part Status Active
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 6
Color Olive Drab
Gender Female
Fastening Type Threaded
Contact Finish - Mating Gold
Current Rating (Amps) 5A 13A
Orientation A
Shielding Shielded
Ingress Protection IP67 - Dust Tight, Waterproof
Reach Compliance Code unknown
Shell Finish Olive Drab Cadmium
Shell Size - Insert 9-200
Contact Style Socket
Insulation Resistance 5GOhm
Cable Opening 0.500 (12.70mm)

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

RoHS Status Non-RoHS Compliant
