2M801-009-07M16-55SA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 6597
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.805 (20.45mm)
Insulation Resistance 5GOhm
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 16-55
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Shielded
Orientation A
Total Number of Contacts 55
Current Rating (Amps) 5A
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Female
Color Silver
Number of Positions 55
Resistance 2.801MOhm
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 2M
Published 2013
Packaging Bulk
Operating Temperature -65°C~150°C
Physical
Insert Material Polyphenylene Sulfide (PPS)
Shell Material Aluminum Alloy
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
