2M801-009-02M16-5PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Cable Opening 0.805 (20.45mm)
Insulation Resistance 5GOhm
Contact Style Pin
Number of Contacts 5
Shell Size - Insert 16-5
Shell Finish Electroless Nickel
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Shielded
Orientation C
Current Rating (Amps) 23A
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Male
Color Silver
Number of Positions 5
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 2M
Published 2011
Packaging Bulk
Operating Temperature -65°C~150°C
Physical
Insert Material Polyphenylene Sulfide (PPS)
Shell Material Aluminum Alloy
Number of Pins 12
Mounting Feature Flange
Mounting Type Panel Mount
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
