TBF32-6PS

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description 32-6 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 135A 500V
PDF
/
Inventory: 9152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

Orientation (Convert To) N (Normal)
Shell Size - Insert (Convert From) 32-6
Orientation (Convert From) N (Normal)
Number of Positions (Convert From) 23
Housing Finish Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Connector Style Standard
Body/Shell Style RECEPTACLE
Empty Shell NO
Housing Color Olive
Voltage - Rated AC 500V
Current Rating 135A
Shielding Unshielded
Total Number of Contacts 23
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating GOLD
Voltage - Rated DC 700V
Fastening Type Threaded
Gender Female
Part Status Active
Pbfree Code no
Series MIL-DTL-5015, CA
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Housing Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 12 Weeks
