TBF28-16PS

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description 28-16 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 22A 500V
PDF
/
Inventory: 3497
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material COPPER ALLOY
Mount Panel
Mounting Type Panel Mount
Mounting Feature Flange
Number of Pins 16
Housing Material Aluminum Alloy

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
JESD-609 Code e4
Pbfree Code no
Part Status Active
Fastening Type Threaded
Voltage - Rated DC 700V
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 20
Shielding Unshielded
Current Rating 22A
Voltage - Rated AC 500V
Contact Gender MALE-FEMALE
Housing Color Olive
Empty Shell NO
Body/Shell Style RECEPTACLE
Connector Style Standard
Contact Finish Termination GOLD
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 20
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 28-16
Orientation (Convert To) N (Normal)

Compliance

RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
