TBF24-12PSW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
24-12 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 135A 500V
PDF
/
Inventory: 10038
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
Technical
Shell Size - Insert (Convert From) 24-12
Orientation (Convert From) W
Number of Positions (Convert From) 5
Housing Finish Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Connector Style Standard
Coupling Type BAYONET
Body/Shell Style RECEPTACLE
Empty Shell NO
Housing Color Olive
Contact Gender MALE-FEMALE
Voltage - Rated AC 500V
Current Rating 135A
Shielding Unshielded
Total Number of Contacts 5
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated DC 700V
Fastening Type Threaded
Part Status Active
Pbfree Code no
Series MIL-DTL-5015, CA
Published 2009
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Aluminum Alloy
Number of Pins 4
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 12 Weeks
